Differential Pressure Control Panels

When pharmaceutical cleanrooms require precise pressure cascade control preventing contaminant migration between adjacent zones, automated damper systems respond to pressure transmitter signals. Differential Pressure Control Panels consolidate pressure controllers, damper actuators, and alarm systems maintaining room-to-room pressure differentials throughout manufacturing facilities.
HY D R O L Y SIS RESIS T ANCE
Material & Grade
  • Stainless Steel – SS304, SS316L
  • Medical-grade stainless steel
  • Cold Rolled Steel – SPCC
  • Electropolished stainless (interior)
  • Sheet thickness – Up to 2.0mm capable
  • Maximum capable – 1200mm (H) x 800mm (W) x 400mm (D)
  • Customizable based on control system requirements
  • Powder Coating – RAL 7035 (Grey), RAL 9010 (White)
  • Thickness – 60-80 microns
  • Electropolished (Stainless Steel)
  • Pharmaceutical-grade finish
  • Easy-clean surface treatment
  • CNC Laser Cutting
  • CNC Punching & Bending
  • TIG/MIG Welding
  • CNC Press Brake Forming
  • Sanitary weld finishing
  • Gasket groove forming
  • Stainless Steel 304/316 Hardware
  • Weather-sealed hinges
  • Quick-release latches
  • Grounding lugs & terminals
  • DIN rail mounting provisions
  • Instrument mounting brackets
Get Latest Price
Get quote

Product Description

Wall-mounted configurations accommodate control instrumentation with external dimensions reaching 1200mm while enabling corridor-side access avoiding cleanroom entry. We engineer organized internal layouts separating low-voltage sensor signals from actuator power circuits preventing electromagnetic interference. Through validated control logic and alarm integration, these panels maintain pressure differentials supporting facility classification and personnel protection in containment applications.

Mounting Type
  • Wall Mount
  • Floor Standing
  • Cleanroom wall integration
  • Corridor-side mounting
  • Universal mounting brackets
  • Vibration-isolated provisions
  • Standard – IP54 (dust/splash protected)
  • Enhanced – IP65 (dust-tight/water jet protected)
  • Cleanroom – IP66 (washdown compatible)
  • Pharmaceutical – NEMA 4 rated
  • Cable glands – M16, M20, M25, M32
  • Bottom/Side entry configurations
  • Sensor tubing penetrations
  • Power and control cable separation
  • Strain relief provisions
  • Sealed cable routing
  • Hinged front door with gasket
  • Transparent viewing window
  • 180° door opening capability
  • Removable panels for installation
  • Tool-required or quick-access
  • Display visibility provisions
  • Natural convection with venting
  • Forced air cooling
  • Operating Temperature – +5°C to +40°C
  • Humidity resistance
  • Heat dissipation provisions
  • Condensation management
  • ISO 14644 (Cleanroom Standards)
  • EU GMP Annex 1 (Cleanroom Manufacturing)
  • FDA 21 CFR Part 11 (Electronic Records)
  • GAMP 5 (Automation Validation)
  • IEC 61439 (Switchgear Assemblies)
  • CE Marked
  • ISO 9001:2015 Manufacturing

Technical Advantages

Pressure control accuracy depends on rapid damper response to pressure fluctuations caused by door openings, equipment operation, or HVAC system changes. Addressing this requirement, proportional-integral-derivative controllers process pressure transmitter signals adjusting damper positions within seconds maintaining setpoints despite disturbances. Organized terminal blocks separate sensor input wiring from damper actuator outputs preventing control signal corruption from electrical noise.

Alarm integration provides visual and audible indication when room pressures deviate beyond acceptable limits threatening cleanroom classification or containment integrity. Transparent viewing windows enable verification of controller displays and alarm status without opening panels during production operations. Moreover, validated control logic with configurable alarm thresholds supports facility-specific pressure cascade schemes documented during commissioning qualification and operational qualification activities.

Let's Get Started

Need reliable Enclosures for your next project? Get in touch with us today, and we’ll help you find exactly what you need!

Contact us

Industry Applications

Sterile Manufacturing Suites

Maintains pressure cascades from Grade A filling zones through Grade B backgrounds to Grade C/D support areas preventing particle ingress.

Containment Laboratories

Controls negative pressure in high-potency compound handling areas protecting personnel from cytotoxic powder exposure during weighing operations.

Biosafety Level Facilities

Manages directional airflow in BSL-2 and BSL-3 laboratories preventing pathogen release during infectious disease research and vaccine production.

Cleanroom Gowning Areas

Regulates pressure relationships between street clothing areas, gowning rooms, and aseptic processing zones supporting personnel flow protocols.

Isolator System Control

Maintains positive or negative pressure in pharmaceutical isolators relative to surrounding cleanroom environments during sterile compounding.

Animal Research Facilities

Controls pressure differentials between animal housing, procedure rooms, and support corridors preventing allergen and pathogen migration.

Differential Pressure Control Panels

Designed for Pressure Control

Control system complexity varies from simple pressure indication with manual damper adjustment to fully automated networks coordinating dozens of cleanroom zones. Differential Pressure Control Panels arrive in configurations supporting basic controllers through distributed control systems with building management system integration.

Corridor-side mounting provisions enable maintenance access without cleanroom entry reducing gowning requirements during routine calibration activities. Frigate manufactures panels supporting 21 CFR Part 11 compliant data acquisition systems with documentation packages including control narratives, alarm setpoint justifications, and validation protocols supporting pharmaceutical facility qualification programs.

Differential Pressure Control Panels

Related products

  • FAQ

Having Doubts? Our FAQ

Check all our Frequently Asked Questions

Get Quote Now
How does Frigate engineer sensor tubing penetrations in Differential Pressure Control Panels maintaining seal integrity while accommodating multiple pressure taps?

Frigate designs dedicated tubing entry points using sealed bulkhead fittings and grommeted penetrations that maintain panel integrity while allowing multiple pressure lines. Layout is planned so tubing remains strain-free and clearly identified, even as additional taps are introduced.

What damper actuator power requirements does Frigate accommodate in Differential Pressure Control Panels supporting various HVAC system configurations?

Actuator compatibility is addressed by supporting –

  • Common AC and DC actuator voltage ranges
  • Dedicated power terminals sized for actuator load
  • Separation between actuator power and control signals

Power provisioning is matched to the HVAC design basis, with Frigate aligning panel capacity to actuator specifications.

Does configurable alarm threshold programming enable facility-specific pressure differential setpoints across different cleanroom classifications?

Yes. Alarm thresholds can be configured to reflect different room classifications, operating modes, and regulatory limits. This flexibility allows pressure limits to be tuned for Grade A, B, C, or D areas without hardware changes.

How does Frigate address condensation management in Differential Pressure Control Panels installed in high-humidity pharmaceutical environments?

Condensation risk is reduced through –

  • Gasketed enclosures with controlled ingress protection
  • Strategic venting or breather elements where required
  • Internal layout that avoids cold-spot contact with sensors

These measures are applied based on ambient conditions defined during design, with Frigate incorporating humidity considerations.

What cable routing separation strategies does Frigate employ in Differential Pressure Control Panels preventing signal interference between control circuits?

Interference control is achieved by –

  • Segregating low-level sensor wiring from power circuits
  • Using dedicated wire ducts for different signal types
  • Maintaining physical separation at terminal blocks

Frigate organizes routing paths to preserve signal accuracy and simplify troubleshooting.

Are modular terminal block arrangements compatible with future zone expansion without requiring complete panel replacement?

Yes. Modular terminal layouts allow spare positions and additional DIN rail space so new zones or sensors can be added later. This approach supports phased expansion without disturbing existing wiring.

How does Frigate design door gasket specifications in Differential Pressure Control Panels maintaining environmental sealing through repeated access cycles?

Door sealing reliability is supported by –

  • Pharmaceutical-grade gasket materials
  • Controlled compression profiles in the door frame
  • Retention methods that prevent gasket displacement

Frigate selects gasket designs to maintain sealing performance across repeated maintenance access.

What display visibility provisions does Frigate integrate in Differential Pressure Control Panels enabling status monitoring from corridor locations?

Visibility is enhanced using –

  • High-contrast displays or indicators
  • Windowed doors or flush-mounted HMIs
  • Viewing angles suitable for corridor observation

Display placement is coordinated so operators can verify status without entering controlled spaces, with Frigate aligning this to layout needs.

Does rapid damper response capability address pressure fluctuations caused by door openings and equipment operation in cleanroom environments?

Yes. Control logic and actuator response are designed to react quickly to transient pressure changes, helping stabilize room differentials during door cycles or process disturbances.

How does Frigate organize internal mounting provisions in Differential Pressure Control Panels accommodating controllers, transmitters, and alarm modules?

Internal organization typically includes –

  • Zoned DIN rail sections for controllers and transmitters
  • Clear spacing for alarm modules and power supplies
  • Logical grouping aligned to signal flow

Frigate structures mounting layouts so components remain accessible, serviceable, and expandable over the panel’s lifecycle.
