Antenna Receiver Enclosure

Signal interference corrupting satellite communication and navigation receivers degrades aircraft positioning accuracy and data link reliability. Antenna Receiver Enclosure provides RF-shielded housings for low-noise amplifiers, downconverters, and signal processing modules.
HY D R O L Y SIS RESIS T ANCE
Material & Grade
  • Aluminum Alloy – 6061-T6, 7075-T6
  • Stainless Steel – SS304
  • Aerospace-grade aluminum
  • Copper-plated aluminum (RF shielding)
  • Sheet thickness: Up to 3.0mm capable
  • Maximum capable: 500mm (H) x 400mm (W) x 300mm (D)
  • Customizable based on receiver module configuration
  • Anodizing – MIL-A-8625 Type II, Type III
  • Powder Coating – Aerospace-grade
  • Conductive coating (EMI shielding)
  • Chromate conversion coating
  • Weather-resistant finish
  • CNC Precision Machining (±0.025mm)
  • CNC Laser Cutting
  • TIG Welding (aerospace-grade)
  • CNC Press Brake Forming
  • RF seam welding
  • EMI gasket groove machining
  • Aerospace-grade fasteners (AN/MS standards)
  • Titanium hardware (weight reduction)
  • EMI/RFI gasket hardware
  • Grounding provisions
  • RF connector mounting provisions
  • Vibration-resistant fasteners
Get Latest Price
Get quote

Product Description

Aircraft-mounted or pod-integrated configurations accommodate receiver hardware with external dimensions reaching 500mm while maintaining electromagnetic isolation. We engineer precision RF sealing preventing external interference from coupling into sensitive receiver front-ends. Through weather protection and vibration isolation, these enclosures enable reliable signal reception supporting aerospace communication systems.

Mounting Type
  • Aircraft fuselage mounting
  • Wing/Tail mounting provisions
  • Avionics rack integration
  • External pod mounting
  • Vibration-isolated mounting
  • Quick-release mechanisms
  • EMI conductive gasket sealing
  • Environmental sealing (IP65-IP67)
  • Altitude compensation vents
  • Pressure equalization provisions
  • Weather-resistant gaskets
  • RF-tight sealing
  • Operating Temperature: -55°C to +85°C
  • Storage Temperature: -62°C to +95°C
  • Altitude: Up to 50,000 feet
  • Humidity: Up to 95% RH
  • Rain/Ice/Sand exposure resistance
  • Lightning strike protection
  • Random vibration tolerance
  • Sine vibration testing
  • Crash impact resistance (MIL-STD-810)
  • Transportation shock qualification
  • Operational vibration isolation
  • RF connector strain relief
  • Shielding Effectiveness: 80-120 dB
  • Frequency range: 100 MHz to 18 GHz
  • Continuous RF seam welding
  • Honeycomb ventilation panels
  • Filtered connector provisions
  • Multi-cavity construction
  • ISO 9001:2015 Manufacturing
  • AS9100 (Aerospace Quality Management)
  • RTCA DO-160 (Environmental Testing)
  • MIL-STD-810 (Environmental Engineering)
  • MIL-STD-461 (EMI/EMC)
  • FAA TSO certification (application-specific)
  • RoHS Compliant

Technical Advantages

Low-noise amplifier performance depends on isolating input stages from local oscillator leakage and external interference sources. Addressing this requirement, multi-cavity construction with internal RF partitions isolates LNA compartments from mixer sections. Continuous RF seam welding creates electromagnetic barriers exceeding 100dB attenuation at frequencies critical to receiver operation.

External antenna mounting exposes receivers to rain, ice, and temperature extremes requiring environmental protection maintaining signal quality. Weather-resistant gaskets prevent moisture ingress that could cause signal degradation through dielectric loading. Moreover, altitude compensation vents prevent pressure differential buildup during rapid altitude changes protecting sealed components.

Let's Get Started

Need reliable Enclosures for your next project? Get in touch with us today, and we’ll help you find exactly what you need!

Contact us

Industry Applications

Satellite Communication Aircraft

Houses satellite receiver modules processing Ka-band and Ku-band signals providing in-flight connectivity services.

Military Reconnaissance Systems

Contains signals intelligence receivers collecting electronic emissions in tactical surveillance aircraft.

Weather Radar Systems

Protects receiver modules processing X-band and C-band radar returns in commercial and military weather avoidance systems.

Air Traffic Control Aircraft

Secures ADS-B and Mode S receivers enabling air traffic surveillance and collision avoidance systems.

Electronic Warfare Platforms

Manages wideband receivers detecting and analyzing threat radar emissions in combat aircraft.

Navigation System Integration

Consolidates GPS, GLONASS, and Galileo receiver modules providing multi-constellation positioning.

Antenna Receiver Enclosure

Crafted for Signal Integrity

Receiver configurations vary from simple single-channel systems to sophisticated multi-band platforms with beam-forming capabilities. Frigate manufactures Antenna Receiver Enclosures meeting RTCA DO-160 environmental qualification with lightning strike protection provisions.

RF connector strain relief provisions prevent cable pull forces during installation from damaging coaxial connections. Vibration-isolated mounting decouples receiver assemblies from airframe vibration preventing mechanical noise from degrading phase-locked loop tracking.

Antenna Receiver Enclosure

Related products

  • FAQ

Having Doubts? Our FAQ

Check all our Frequently Asked Questions

Get Quote Now
Can multi-cavity construction with internal RF partitions in Antenna Receiver Enclosures isolate LNA compartments from mixer sections?

Multi-cavity construction is commonly specified to control coupling between sensitive RF stages. Frigate manufactures Antenna Receiver Enclosures with internal RF partitions based on customer-defined layouts, allowing physical separation between LNA compartments and mixer sections. Partition count, spacing, and wall thickness are typically customized to match frequency bands and receiver architecture requirements.

How does Frigate achieve continuous RF seam welding in Antenna Receiver Enclosures creating attenuation exceeding 100dB?

High shielding effectiveness is achieved during fabrication by Frigate through –

  • Continuous seam welding applied per specified RF leakage limits
  • Controlled weld depth and bead uniformity to avoid micro-gaps
  • Post-weld finishing to maintain electrical continuity

Welding patterns and inspection criteria are adapted based on enclosure size and attenuation targets.

Are weather-resistant gaskets effective preventing moisture ingress that could cause signal degradation through dielectric loading?

Environmental sealing is critical for RF stability, and Frigate incorporates gasket systems that –

  • Maintain compression across temperature cycling
  • Resist UV exposure and environmental aging
  • Preserve electrical continuity across removable panels

Gasket materials and profiles are selected based on operating environment and access frequency.

How does Frigate integrate altitude compensation vents in Antenna Receiver Enclosures preventing pressure differential during rapid altitude changes?

Pressure equalization provisions are implemented during manufacturing by Frigate using –

  • Breather or membrane vents specified for altitude profiles
  • Moisture- and particulate-blocking vent elements
  • Mounting locations that preserve shielding performance

Vent selection and placement are customized based on deployment altitude and enclosure volume.

Does RF connector strain relief prevent cable pull forces from damaging coaxial connections during installation?

Cable-induced mechanical stress can affect connector reliability over time. Frigate manufactures enclosures with connector mounting reinforcement and strain relief provisions based on customer requirements, allowing cable loads to be transferred into the enclosure structure rather than the connector interface. Strain relief geometry is typically customized according to cable size, connector type, and routing constraints provided in installation drawings.

How does Frigate address vibration-isolated mounting in Antenna Receiver Enclosures preventing mechanical noise from degrading phase-locked loop tracking?

Vibration control features are incorporated by Frigate through –

  • Isolation mounts specified for platform vibration spectra
  • Structural reinforcement at mounting points
  • Mass distribution aligned with customer vibration limits

Isolation hardware and attachment schemes are adapted based on aircraft, vehicle, or fixed-site conditions.

Can lightning strike protection provisions support external antenna mounting in weather radar and communication systems?

External antenna interfaces often require defined lightning protection paths. Frigate manufactures enclosures with grounding points, bonding surfaces, and surge diversion provisions aligned to customer-specified lightning protection standards. These features are implemented according to installation drawings and applicable zoning requirements.

How does Frigate validate RTCA DO-160 environmental qualification in Antenna Receiver Enclosures with complete test documentation?

Environmental qualification relies on controlled manufacturing and documented verification. Frigate builds Antenna Receiver Enclosures using materials, finishes, and sealing methods aligned to RTCA DO-160 categories, supporting qualification testing for temperature, vibration, humidity, and EMI. Test scope and documentation are typically aligned with program certification plans.

Are honeycomb ventilation panels compatible with thermal management requirements in high-power satellite receiver applications?

Thermal airflow requirements are supported by Frigate using honeycomb ventilation panels that –

  • Allow airflow with minimal pressure drop
  • Maintain RF attenuation across specified bands
  • Integrate mechanically into shielded walls

Cell size, panel depth, and material finish are selected based on heat dissipation and shielding requirements.

How does Frigate optimize precision RF sealing in Antenna Receiver Enclosures preventing external interference from coupling into receiver front-ends?

Consistent RF sealing is achieved during fabrication by Frigate through –

  • Precision-machined gasket grooves for uniform compression
  • Controlled flatness of mating panels
  • Coordinated sealing around connectors, vents, and access covers

Sealing strategies are customized based on frequency sensitivity and enclosure access requirements
