Wheel Balance Weights

Frigate manufactures premium-grade wheel balance weights engineered to eliminate rotational vibration and ensure flawless assembly performance. Designed for high-speed stability and demanding fleet environments, our weights provide exact mass distribution for light vehicles, heavy trucks, and specialized industrial machinery.

Material Options

Fe (Iron), Zn (Zinc), Pb (Lead – Available upon regulatory compliance)

Type Configuration

Adhesive (Stick-on) strips & Clip-on variants

Surface Treatment

Multi-layer Zinc Plating / Epoxy Powder Coating / Anti-corrosion Passivation

Salt Spray Resistance

≥ 500 Hours (ASTM B117 testing without red rust)

Adhesive Tape Type

Premium High-Shear Blue/White Tape (Norton / 3M equivalent)

*Note: Timelines shown are indicative and depend on raw material availability, custom tooling requirements, and shipping configurations. Exact delivery windows are finalized upon drawing approval.

Product Description

Our comprehensive range of adhesive and clip-on wheel balance weights delivers precision calibration to protect drivetrain components from premature wear and uneven tire degradation. Manufactured under strict ISO 9001 quality standards, Frigate ensures every weight offers exceptional surface adhesion, corrosion resistance, and exact dimensional tolerances for seamless OEM integration.

Peel Adherence Strength

≥ 45 N / 25 mm

Weight Increments (Adhesive)

5g, 10g, 1 / 4 oz, 1 / 2 oz segments

Profile Configurations

Ultra-low profile (3.8 mm) / Standard profile (4.8 mm)

Rim Application Types

Al (Aluminum/Alloy), Fe (Steel/Passenger), J-Type, Flanged Rims

Clip Material

Hardened Carbon Steel with high elasticity retention

Manufacturing Process

Precision Cold Stamping / Automated Die-Casting

Operating Temperature Range

-40 ° C to +120° C

Hardness (Fe Cores)

≤ 65 HRB (Prevents rim scratching during installation)

Compliance & Standards

ELV Directive (2000/53/EC), REACH, RoHS Certified

Quality Certification

IATF 16949 / ISO 9001:2015 Manufacturing Infrastructure

Technical Advantages

Engineered with eco-friendly materials and high-shear adhesive backings, Frigate wheel weights guarantee unyielding retention under extreme thermal and mechanical stress. The advanced multi-layer zinc or iron plating provides superior salt-spray corrosion resistance, ensuring long-term balancing accuracy in the harshest road environments.

Let's Get Started

Need reliable Enclosure for your next project? Get in touch with us today, and we’ll help you find exactly what you need!

Industry Applications

Passenger Vehicle OEMs

Supplying precision-engineered adhesive strips and alloy-compatible clip-on weights directly to Tier-1 assembly lines for high-volume consumer automotive production.

Commercial Fleet & Trucking

Heavy-duty, high-mass balance weights designed specifically for commercial trucks, buses, and long-haul trailers facing severe rotational stresses.

Off-Highway & Construction

Ruggedized balancing solutions for agricultural machinery and earthmoving equipment, built to endure high vibration, impact, and mud accumulation.

Electric Vehicle (EV) Platforms

Ultra-low profile, aerodynamically optimized weights designed to clear tight caliper tolerances while meeting strict weight-distribution parameters for EVs.

Defense & Armored Vehicles

Specialized, high-durability balancing segments built to military specifications, maintaining tactical mobility and wheel structural integrity under field strain.

Aftermarket Distribution Networks

Mass-volume packaging solutions customized for global tier-1 distributors, detailing clear weight markings and pre-segmented strips for fast workshop turnover.

Frigate Approved Quality Management System

At Frigate, quality is built into every stage of manufacturing. Our approved Quality Management System ensures that every material component.

Incoming Material Checking

Before production begins, all incoming materials are checked against specifications, drawings, and supplier documents.

In-Process Inspection

Quality is monitored during manufacturing to prevent defects and maintain process consistency.

Final Dimensional Checking

Finished parts are inspected before dispatch to confirm compliance with customer drawings and tolerances.

Packaging Control

Finished components are packed safely to prevent damage during handling and transportation.

Incoming Material Checking

In-Process Inspection

Final Dimensional Checking

Packaging Control

Quality Document

To help buyers evaluate our quality systems, we provide sample documents that reflect our inspection and reporting standards.

How We Delivered

Complex geometries engineered solutions that move businesses forward.

Solar Inverter Enclosure

units per month

Bento Boxes for D2C Segment

Units Manufactured Monthly

0 +

Defence-Grade Cable Supply

Cost savings

0 %

Flange Assembly for Pump

Faster Production

0 %

Having Doubts? Our FAQ

Can Frigate customize the clip profiles to match our proprietary OEM rim geometries?

Yes. We regularly manufacture custom clip profiles based on customer-provided 3D CAD files or physical rim samples to ensure exact tension retention and prevent rim flange damage during automated assembly.

What adhesive backing tape do you use, and how does it perform during cold-weather assembly?

We standardly utilize high-shear, automotive-grade acrylic foam tapes (such as Norbond or 3M equivalents). For optimal adhesion, we recommend an application environment above 15° C, though our tape is rated to maintain its bond integrity down to -40° C once fully cured.

How does Frigate guarantee mass accuracy across a high-volume production batch?

Our production lines utilize automated inline load-cell weighing systems and continuous statistical process control (SPC). Every single batch undergoes strict dimensional and weight tolerance screening to guarantee deviations stay within ± 1% or ± 0.5g.

Do you provide specialized surface coatings for vehicles operating in coastal or highly corrosive environments?

Yes, we offer advanced multi-layer epoxy powder coatings and specialized zinc-nickel plating. These treatments are tested to withstand over 500 hours of continuous salt spray exposure (per ASTM B117) without exhibiting red rust.

Can we set up a blanket order with scheduled Just-In-Time (JIT) deliveries to manage our warehouse inventory?

Absolutely. We routinely partner with OEMs on annual blanket contracts, holding safety stock in our facilities to facilitate predictable, scheduled JIT monthly or weekly deliveries based on your rolling production forecasts.
