Turret Slip Rings

At Frigate, we engineer military-grade Turret Slip Rings that deliver uninterrupted 360° electrical connectivity, high-speed data transmission, and fluid power for modern defense platforms. Built to withstand extreme combat environments, our slip rings ensure flawless operational readiness and precision performance when it matters most.

Circuit Configuration

Up to 120 power and signal channels

Current Capacity

Signal paths (mA) up to High-Power channels (150A per circuit)

Voltage Rating

Up to 1000 V AC/DC

Dielectric Strength

≥ 2000 V AC at 50 Hz between circuits

Insulation Resistance

≥ 1000 M Ω at 500 VDC

Order Type

Quantity Range

Lead Time*

Standard / COTS Configuration

1 – 5 Units

4 – 6 Weeks

Custom Batch Production

6 – 25 Units

8 – 12 Weeks

Full-Scale Deployment Fleet

26+ Units

14 – 18 Weeks (Staggered delivery available)

*These timelines are indicative ranges. Actual delivery schedules depend heavily on specific material sourcing requirements, custom engineering modifications, and stringent military testing protocols.

Product Description

Frigate’s Turret Slip Rings serve as the critical electro-mechanical backbone for armored vehicles, naval mounts, and weapon systems by bridging static and rotating platforms. They seamlessly manage high-power distribution alongside sensitive, low-latency sensor data streams under intense thermal and physical stress.

Data & Signal Compatibility

Ethernet (1Gbps), Mil-Std-1553, HD-SDI, CANbus, and Fiber Optic (FORJ)

Contact Material

Gold-on-Gold fiber brush / Precious metal alloy

Housing Material

Heavy-duty Aluminum (6061-T6/7075) or Stainless Steel with chemical conversion coating

Operating Speed

Continuous rotation up to 250 RPM

Ingress Protection (IP)

IP65, IP66, or IP67 sealed variants available

Operating Temperature

-55 ° C to +85 ° C (Extended military range)

Shock & Vibration

Fully compliant with MIL-STD-810G and MIL-STD-167

Electromagnetic Shielding

MIL-STD-461 compliant EMI/EMC shielding

Rotational Life

≥ 50 million revolutions (maintenance-free)

Integrated Fluid Rotary Unions

Optional integration for hydraulic, pneumatic, or coolant lines

Technical Advantages

By utilizing advanced gold-on-gold multi-fiber brush technology, our slip rings minimize electrical noise and mechanical wear, eliminating the need for periodic field lubrication. This robust design guarantees an exceptionally high total cost of ownership (TCO) efficiency through a maintenance-free 50-million-revolution lifespan.

Let's Get Started

Need reliable Enclosure for your next project? Get in touch with us today, and we’ll help you find exactly what you need!

Industry Applications

Armored Fighting Vehicles (AFVs)

Provides continuous power and high-speed data to main battle tank turrets, ensuring 360° situational awareness, target tracking, and fire-control stability.

Remote Weapon Stations (RWS)

Enables compact, high-reliability power and video signal transmission for automated machine guns and missile launchers deployed on tactical vehicles.

Naval Gun Mounts & CIWS

Delivers ruggedized, corrosion-resistant electrical connections for rapid-firing naval artillery and Close-In Weapon Systems exposed to harsh maritime environments.

Radar and Surveillance Systems

Facilitates uninterrupted rotation for air defense tracking arrays, ensuring constant feed of critical target acquisition data without latency.

Unmanned Ground Vehicles (UGVs)

Supports the compact, lightweight integration of power and control systems in autonomous defense platforms operating across unpredictable, high-vibration terrain.

Aerospace Turrets & EO/IR Pods

Sustains high-bandwidth fiber optic connections for stabilized electro-optical and infrared imaging payloads mounted on defense aircraft and helicopters.

Frigate Approved Quality Management System

At Frigate, quality is built into every stage of manufacturing. Our approved Quality Management System ensures that every material component.

Incoming Material Checking

Before production begins, all incoming materials are checked against specifications, drawings, and supplier documents.

In-Process Inspection

Quality is monitored during manufacturing to prevent defects and maintain process consistency.

Final Dimensional Checking

Finished parts are inspected before dispatch to confirm compliance with customer drawings and tolerances.

Packaging Control

Finished components are packed safely to prevent damage during handling and transportation.

Incoming Material Checking

In-Process Inspection

Final Dimensional Checking

Packaging Control

Quality Document

To help buyers evaluate our quality systems, we provide sample documents that reflect our inspection and reporting standards.

How We Delivered

Complex geometries engineered solutions that move businesses forward.

Solar Inverter Enclosure

units per month

Bento Boxes for D2C Segment

Units Manufactured Monthly

0 +

Defence-Grade Cable Supply

Cost savings

0 %

Flange Assembly for Pump

Faster Production

0 %

Having Doubts? Our FAQ

Can Frigate customize slip rings to include hydraulic or pneumatic lines?

Yes. Our turret slip rings can be fully integrated with multi-passage fluid rotary unions to transmit hydraulic fluids, pneumatic pressure, or liquid coolants alongside electrical power and high-frequency signals.

How do your slip rings perform under heavy EMI/EMC conditions?

Our products are engineered with robust internal shielding and isolation barriers designed to meet strict MIL-STD-461 standards. This prevents cross-talk between high-current power lines and sensitive communication data links.

What military standards are these slip rings validated against?

Frigate’s defense-grade slip rings are designed, tested, and certified to meet compliance for MIL-STD-810G (environmental, shock, and vibration), MIL-STD-461 (electromagnetic interference), and MIL-STD-167 (naval vibration).

What is the typical maintenance cycle for gold-on-gold fiber brush systems?

Our advanced precious metal fiber brush technology is virtually maintenance-free. It does not require lubrication or debris cleaning over its rated operational life of up to 50 million revolutions, significantly lowering field downtime.

How do we initiate a custom design review for a specific defense platform?

You can submit your technical parameter requirements and CAD files directly through our procurement portal. Our engineering team will review the specifications to provide a detailed Design for Manufacturing (DFM) and technical proposal.
