Tank Bracket (Satellite)

Engineered for missions where failure is not an option, Frigate’s high-precision satellite tank brackets deliver critical structural integrity for complex orbital payloads. Our flight-ready components minimize parasitic mass while maximizing load-bearing capacity under extreme launch vibrations.

Primary Material Grade

Aluminum-Lithium 2195 / Titanium Ti-6Al-4V ELI (Grade 23)

Manufacturing Process

5-Axis CNC Machining / Friction Stir Welding / Additive Manufacturing (LPBF)

Dimensional Tolerance

Down to ±0.005 mm (± 0.0002 inches)

Surface Roughness

Ra ≤ 0.8 μm (As-machined) / Ra ≤ 0.4 μm (Electropolished)

Nondestructive Testing (NDT)

ASTM E1417 Dye Penetrant / ASTM E1742 X-Ray Radiography

Order Type

Quantity Range

Lead Time*

Sample & Qualification

1 – 3 Units

4 – 6 Weeks

Low-Rate Initial Production (LRIP)

4 – 15 Units

8 – 10 Weeks

Full-Rate Flight Production

16 – 50+ Units

12 – 16 Weeks

Fast-Track / AOG Allocation

Subject to Raw Stock

3 – 4 Weeks

*Listed lead times are indicative ranges based on raw material availability. Final schedules depend on specific material grade sourcing and custom NDT requirements.

Product Description

Frigate’s Satellite Tank Brackets are high-performance structural mounts optimized to securely anchor propellant and pressurant tanks within spacecraft busses. Utilizing advanced generative design and aerospace-grade materials, these brackets bridge the critical gap between stringent weight reduction targets and high launch vehicle load demands.

Mass Reduction Optimization

Generative Design / Topology Optimized Topology Structure

Design Load Factor

Up to 15g Static / 22g Root-Mean-Square (RMS) Random Vibration

Operating Temperature Range

-196 ° C to +200 ° C (Cryogenic to High Orbital Thermal Fluctuations)

Surface Treatment / Coating

MIL-A-8625 Type III Hardcoat Anodizing / Chem Film Chromate Conversion

Threaded Inserts & Fasteners

MS/NAS Standard Helical Wire Inserts (Nitronic 60 / Locking)

Outgassing Compliance

NASA SP-R-0022A Standard (CVCM < 0.1%, TML < 1.0%)

Interface Flatness

Within 0.02 mm across mating surfaces

Co-ordinate Measuring (CMM)

AS9102 Rev C First Article Inspection (FAI) Report Compliant

Applicable Launch Environs

Geostationary (GEO), Low Earth Orbit (LEO), and Deep Space Missions

Cleanroom Assembly Level

ISO Class 7 (Class 10,000) certified bagging and handling

Technical Advantages

Frigate’s satellite tank brackets feature an optimized strength-to-weight ratio achieved through monolithic 5-axis machining, which removes every microgram of unnecessary mass to drastically reduce the total cost of ownership per kilogram launched. Furthermore, these components are engineered specifically to damp severe acoustic and random launch vibration profiles, eliminating stress concentrations at critical tank interfaces to ensure mission success.
