Support Girders

Partnering with Frigate ensures your large-scale infrastructure projects are anchored by heavy-duty support girders engineered for extreme load-bearing capacity and uncompromising structural integrity. Our precision-fabricated girders optimize structural efficiency and safely absorb high dynamic loads across bridges, industrial complexes, and transit networks.

Material Grade

IS 2062 E250/E350, ASTM A572 Grade 50, EN 10025 S355JR

Yield Strength (σ y)

250 MPa to 350 MPa (subject to material grade selection)

Ultimate Tensile Strength

410 MPa to 490 MPa

Flange Width Range

200 mm to 800 mm

Web Thickness Range

8 mm to 50 mm

Order Type

Quantity Range

Lead Time*

Sample / First Article

1 to 5 Metric Tons

3 to 4 Weeks

Batch Production (Medium Scale)

6 to 50 Metric Tons

5 to 7 Weeks

Mass Infrastructure Supply

50+ Metric Tons

8 to 12 Weeks (Staggered dispatches available)

*Timelines are indicative and depend on raw material availability, design approvals, and drawing freezes. Final delivery schedules are committed upon order finalization.

Product Description

Frigate’s high-performance support girders are custom-engineered from premium structural steel to withstand rigorous mechanical stress and environmental challenges in massive infrastructure projects. By integrating advanced welding technology and precise geometric tolerances, these girders provide the foundational backbone necessary for safe, long-term structural reliability.

Section Depth/Height

Up to 2500 mm built-up custom profiles

Length Profiles

Single span up to 18 meters without spliced joints

Welding Process

Submerged Arc Welding (SAW) & Gas Metal Arc Welding (GMAW)

Nondestructive Testing (NDT)

100% Ultrasonic Testing (UT) & Magnetic Particle Testing (MPT)

Deflection Limit Standard

Compliant with IS 800 / BS 5950 structural limits

Surface Treatment

Shot blasting to Sa 2.5, followed by Epoxy/Polyurethane coating

Corrosion Resistance

Hot-dip galvanized or zinc-rich primer coating up to 120 μm

Dimensional Tolerances

Strictly adhering to ISO 13920 class B (welding) and EN 10034

Load Capacity Range

Custom rated from 50 kN/m to 500 kN/m distributed load

Manufacturing Certifications

ISO 9001:2015, ISO 3834-2, CE Marking compliant

Technical Advantages

Our support girders feature optimized cross-sectional designs that deliver an exceptional strength-to-weight ratio, significantly reducing overall material costs while maximizing load distribution efficiency. Additionally, each girder undergoes advanced metallurgical surface treatments, ensuring superior resistance to corrosion, fatigue, and seismic vibrations in high-stakes industrial environments.

Let's Get Started

Need reliable Enclosure for your next project? Get in touch with us today, and we’ll help you find exactly what you need!

Industry Applications

Highway & Railway Bridges

Engineered to bear continuous dynamic stresses and heavy rolling loads. They provide structural stability for long-span overpasses and high-speed rail networks.

Industrial Warehouses

Ideal for massive clear-span logistics hubs and manufacturing facilities. These girders eliminate intermediate columns to maximize usable floor space.

Metro Elevated Corridors

Custom-curved and fabricated to support heavy mass transit rail tracks. They ensure minimal deflection and strict compliance with urban safety standards.

Heavy Overhead Crane Runways

Designed to withstand severe cyclic wheel loads and high torque forces. They provide a rigid, reliable track framework for heavy-duty industrial EOT cranes.

High-Rise Commercial Buildings

Acts as the primary load-bearing matrix for multi-story steel structures. They efficiently transfer vertical and lateral wind loads to foundations.

Power Plants & Refineries

Heavy structural framing capable of supporting massive process equipment, cooling towers, and high-temperature piping manifolds under extreme conditions.

Frigate Approved Quality Management System

At Frigate, quality is built into every stage of manufacturing. Our approved Quality Management System ensures that every material component.

Incoming Material Checking

Before production begins, all incoming materials are checked against specifications, drawings, and supplier documents.

In-Process Inspection

Quality is monitored during manufacturing to prevent defects and maintain process consistency.

Final Dimensional Checking

Finished parts are inspected before dispatch to confirm compliance with customer drawings and tolerances.

Packaging Control

Finished components are packed safely to prevent damage during handling and transportation.

Incoming Material Checking

In-Process Inspection

Final Dimensional Checking

Packaging Control

Quality Document

To help buyers evaluate our quality systems, we provide sample documents that reflect our inspection and reporting standards.

How We Delivered

Complex geometries engineered solutions that move businesses forward.

Solar Inverter Enclosure

units per month

Bento Boxes for D2C Segment

Units Manufactured Monthly

0 +

Defence-Grade Cable Supply

Cost savings

0 %

Flange Assembly for Pump

Faster Production

0 %

Having Doubts? Our FAQ

Can Frigate customize girder profiles based on project-specific Finite Element Analysis (FEA) models?

Yes. Our engineering team reviews your design packages, structural parameters, and FEA data to fabricate custom built-up plates and tailored beam sections that perfectly match your exact load requirements.

What quality documentation and certifications accompany each batch of support girders?

We provide comprehensive Quality Assurance Books including Mill Test Certificates (MTC), NDT reports (Ultrasonic and Radiography tests), blasting profile proofs, coating thickness (DFT) logs, and final dimensional inspection reports.

How does Frigate optimize the total cost of ownership (TCO) and lead times for large structural rollouts?

Through our strong strategic sourcing network for raw steel plates and automated high-efficiency welding lines, we minimize material wastage, secure volume discounts, and compress production cycles to ensure highly predictable lead times.

Do you offer specialized anti-corrosive coatings for girders deployed in coastal or high-humidity environments?

Absolutely. We offer heavy-duty surface protections including hot-dip galvanization, multi-coat epoxy systems, and marine-grade polyurethane coatings designed to withstand aggressive atmospheric corrosion class C4 and C5 environments.

What are your shipping and logistics capabilities for handling over-dimensional cargo (ODC)?

Frigate manages complete logistics for oversized, heavy-built girders. We handle everything from specialized multi-axle trailers and transport routing permissions to ensuring secure tie-downs, preventing structural warping during transit.
