PCB SMT Assembly

Frigate delivers enterprise-grade Surface Mount Technology (SMT) assembly, leveraging advanced automated placement lines to ensure flawless component registration and solder joint integrity. We scale seamlessly from rapid NPI prototyping to high-volume production, adhering to strict IPC-A-610 Class 2 and Class 3 standards for mission-critical electronics.

Assembly Types

Rigid, Flexible, Rigid-Flex, and Metal Core PCBs

Component Placement Pitch

High-precision down to 0.3 mm for fine-pitch BGAs and QFNs

Minimum Component Size

01005 (0402 metric) ultra-miniature passives

Maximum Board Dimensions

Up to 510 mm x 460 mm (20.0 x 18.1 inches)

Minimum Board Dimensions

Down to 50 mm x 50 mm (1.9 x 1.9 inches)

*Note: Timelines are indicative and depend on component availability, board complexity, and engineering verification (DFM). Actual schedules are finalized upon receipt of complete Gerber files and BOM.

Product Description

Optimize your hardware supply chain with Frigate’s agile SMT assembly solutions built for speed and repeatability. By pairing advanced automated pick-and-place technology with meticulous inspection protocols, we compress your manufacturing timelines without ever compromising on structural or electrical integrity.

Board Thickness Range

0.4 mm to 6.0 mm (0.016 to 0.24 inches)

Max Component Height

Up to 25 mm standard automated clearance

Solder Types Available

Lead-free (RoHS compliant) SAC305, Leaded, and No-Clean pastes

Inspection Technologies

3D Automated Solder Paste Inspection (SPI) & 3D Automated Optical Inspection (AOI)

Testing Capabilities

In-Circuit Testing (ICT), Flying Probe Testing, and Functional Circuit Testing (FCT)

X-Ray Inspection (AXI)

High-resolution 2D/3D X-ray for hidden solder joint validation on BGA and LGA

Surface Finishes Supported

ENIG, HASL, Lead-Free HASL, OSP, Immersion Silver, and ENEPIG

Layer Count Capability

1 to 64 layers for complex multilayer HDI architectures

Trace and Space

Ultra-fine line capability down to 2.5 mil (0.063 mm)

Conformal Coating

Automated selective spray coating and acrylic/silicone dipping available

Technical Advantages

By employing real-time 3D SPI and AOI monitoring, we virtually eliminate bridging, voiding, and misalignment errors during the reflow process. Our optimized component profiling and multi-zone reflow ovens ensure stable thermal transitions, protecting sensitive ICs and delivering robust, high-vibration-resistant solder joints.

Let's Get Started

Need reliable Enclosure for your next project? Get in touch with us today, and we’ll help you find exactly what you need!

Industry Applications

Automotive Electronics

High-reliability assemblies for ECU systems, EV battery management modules, advanced driver-assistance systems (ADAS), and ruggedized sensor arrays.

Aerospace & Defense

Mission-critical PCBAs compliant with strict standards, built for extreme environments, radar systems, telemetry, and avionics control.

Industrial Automation

Heavy-duty controllers, PLC modules, power distribution units, and variable frequency drives engineered for high uptime and thermal stress resilience.

Medical Devices

Class 3 medical electronics including patient monitoring equipment, diagnostic imaging systems, and implantable device controllers requiring zero-defect validation.

Telecommunications

High-speed network switches, 5G base station hardware, RF transceivers, and router motherboards utilizing complex, fine-pitch HDI structures.

Consumer Technology & IoT

Compact, high-density smart home devices, wearable electronics, and energy-efficient connected appliances optimized for cost-effective, rapid-scale production.

Frigate Approved Quality Management System

At Frigate, quality is built into every stage of manufacturing. Our approved Quality Management System ensures that every material component.

Incoming Material Checking

Before production begins, all incoming materials are checked against specifications, drawings, and supplier documents.

In-Process Inspection

Quality is monitored during manufacturing to prevent defects and maintain process consistency.

Final Dimensional Checking

Finished parts are inspected before dispatch to confirm compliance with customer drawings and tolerances.

Packaging Control

Finished components are packed safely to prevent damage during handling and transportation.

Incoming Material Checking

In-Process Inspection

Final Dimensional Checking

Packaging Control

Quality Document

To help buyers evaluate our quality systems, we provide sample documents that reflect our inspection and reporting standards.

How We Delivered

Complex geometries engineered solutions that move businesses forward.

Solar Inverter Enclosure

units per month

Bento Boxes for D2C Segment

Units Manufactured Monthly

0 +

Defence-Grade Cable Supply

Cost savings

0 %

Flange Assembly for Pump

Faster Production

0 %

Having Doubts? Our FAQ

Does Frigate support double-sided SMT assembly and mixed-technology (SMT + Through-Hole) boards?

Absolutely. Our production lines are fully equipped for multi-pass reflow processing to handle dense double-sided SMT layouts. We also feature wave soldering and selective soldering infrastructure to seamlessly integrate through-hole components on the same assembly.

Are laser-cut stencils and setup fixtures included in the initial tooling quote?

Yes, all necessary high-precision laser-cut stencils, pick-and-place programming, and custom reflow fixtures are calculated and clearly itemized in our initial engineering and tooling quote. This ensures complete transparency with no hidden setup fees when transitioning to production.

How do you guarantee the quality of fine-pitch BGA and LGA placements?

Every board with BGA, LGA, or QFN components undergoes mandatory, automated 3D X-ray inspection (AXI) post-reflow to screen for hidden internal defects like solder voiding, bridging, and micro-cracking that standard optical inspection cannot detect.

Do you perform Design for Manufacturability (DFM) reviews before assembly begins?

Yes, our engineering team conducts a comprehensive DFM and DFT (Design for Testing) analysis on every project before releasing it to production to identify footprint mismatches, trace clearance risks, or thermal imbalances that could impact yield.

Are your SMT processes compliant with environmental and safety standards?

Absolutely. Frigate operates fully compliant lead-free and RoHS-certified production lines, and our facilities are certified to ISO 9001:2015 standards, ensuring complete trace-ability and consistent quality across all production batches.
