MIL-W-5846 Thermocouple Extension Cable

Partner with Frigate for high-reliability MIL-W-5846 thermocouple extension cables, precision-engineered to sustain critical temperature data integrity in harsh aerospace and defense environments. Our military-grade cables ensure seamless, low-error signal transmission between engine sensors and instrumentation instrumentation disks under extreme thermal stress.

Military Specification

MIL-W-5846

Calibration Type

Type K (Chromel / Alumel)

Conductor Materials

Chromel (Positive leg) / Alumel (Negative leg)

Temperature Range

Continuous -55C to +200C (Intermittent up to +260° C)

Voltage Rating

600 Volts RMS maximum

*Note: Listed timeframes are indicative ranges based on standard material availability; exact delivery schedules will be locked in upon formal RFQ evaluation.

Product Description

Frigate’s MIL-W-5846 thermocouple extension cables are specialized, high-accuracy links explicitly designed to extend temperature sensor signals without introducing thermal EMF errors. Built to rigid defense standards, these cables provide the rugged durability and precise shielding required for volatile aerospace engine testing and exhaust monitoring.

Insulation Material

Extruded PTFE (Polytetrafluoroethylene) or fused Kapton tape

Jacket Material

High-density braided fiberglass with silicone/PTFE impregnant

Shielding Options

Stainless steel braid, tin-plated copper, or silver-plated copper

Conductor Configuration

Solid or stranded (commonly 16 AWG to 24 AWG)

Limits of Error

Conforms to ASTM E230 Standard Tolerances / Special Limits

Corrosion Resistance

Excellent resistance to aviation fuels, hydraulic fluids, and solvents

Flame Retardancy

Self-extinguishing, meets strict military flame propagation tests

Tensile Strength

High-strength core structures tailored for high-vibration airframe routing

Identification

Color-coded according to military standards (M5846 markers)

Quality Compliance

AS9100 Rev D certified production, fully traceable melt lots

Technical Advantages

By utilizing exact match-grade Chromel-Alumel conductors and high-density outer braiding, Frigate minimizes signal attenuation and eliminates ambient electromagnetic interference in high-density wiring harnesses. The advanced PTFE and fiberglass insulation systems resist chemical degradation from jet fuels and hydraulic fluids while maintaining flexibility at sub-zero temperatures.
