Instrumentation Wiring Harnesses

Precision-Engineered Connectivity for High-Volume Consumer Goods Manufacturing. Frigate supplies turnkey, industrial-grade instrumentation wiring harnesses designed to withstand thermal cycling, vibration, and rigorous duty cycles in modern appliances and consumer electronics.

Conductor Materials

High-purity Electrolytic Tough Pitch (ETP) Copper, Tinned Copper

Wire Gauge Range (AWG)

12 AWG to 28 AWG (Custom configurations available)

Insulation Types

PVC, XLPE, PTFE, Tefzel (FEP)

Jacket/Sheath Material

Flame-retardant LSZH (Low Smoke Zero Halogen), Polyurethane, or Nylon

Maximum Operating Voltage

300V / 600V AC/DC (Depending on insulation class)

Order Type

Quantity Range

Lead Time*

Sample / First Article

5 – 50 Units

2 – 3 Weeks

Low-Volume Batch (NPI)

51 – 1,000 Units

4 – 5 Weeks

Medium-Volume Run

1,001 – 10,000 Units

6 – 8 Weeks

High-Volume Mass Production

10,001+ Units

8 – 10 Weeks (Blanket order schedules available)

*These timelines are indicative ranges based on standard component availability. Actual lead times may vary depending on material sourcing, custom tooling requirements, and production capacity at the time of order placement.

Product Description

Frigate’s instrumentation wiring harnesses serve as the central nervous system for complex consumer appliances, ensuring flawless signal integrity and power distribution. Engineered for high-density layouts, our localized routing solutions mitigate electromagnetic interference (EMI) to guarantee long-term product reliability and safety.

Temperature Rating

-40°C to +105°C (Standard); up to +200°C (High-Temp PTFE)

Connector Integration

Molex, Amphenol, JST, TE Connectivity, or Custom Equivalents

Terminal Pitch Options

1.0mm, 2.0mm, 2.54mm, 3.96mm, up to 4.2mm

Shielding Efficiency

Al-Mylar Tape with Braided Copper Drain Wire (> 85% coverage)

Dielectric Strength

2.0 kV AC for 1 minute (No breakdown)

Insulation Resistance

≥ 100 M Ω at 500 V DC

Flame Retardancy Rating

UL94 V-0, VW-1, and CSA FT1 compliant

Compliance & Standards

UL/cUL Recognized, RoHS 3, REACH, IPC-A-620 Class 2 & 3

Testing Protocols

100% Continuity, Continuity Resistance, and High-Pot Testing

Environmental Protection

IP65, IP67, or IP68 rated sealing options available

Technical Advantages

Our harnesses utilize automated, precision-crimped terminations that eliminate variance and significantly reduce Total Cost of Ownership (TCO) by preventing field failures. Designed for plug-and-play integration, they minimize assembly errors on your factory floor, accelerating your overall time-to-market.

Let's Get Started

Need reliable Enclosure for your next project? Get in touch with us today, and we’ll help you find exactly what you need!

Industry Applications

Smart Home Appliances

Optimized for IoT-enabled refrigerators, washing machines, and ovens, ensuring stable data transmission and sensor arrays under continuous use.

HVAC Systems & Thermostats

Engineered to withstand prolonged thermal fluctuations and humidity in climate control units, maintaining precise sensory voltage signals.

Water Purifiers & Dispensers

Features moisture-resistant insulation and sealed connectors to prevent short circuits in high-humidity fluid management environments.

Consumer Robotics & Vacuums

High-flex life wiring designed to endure continuous dynamic movement and internal structural vibration without micro-disconnections.

Personal Care Electronics

Compact, space-saving micro-wire harnesses tailored for high-density architectures inside premium grooming and wellness devices.

Entertainment & Gaming Consoles

Shielded instrumentation wiring that prevents internal EMI crossover, ensuring uninterrupted high-frequency signal processing.
