Hydraulic Manifold

Engineered to withstand extreme high-pressure and corrosive environments, Frigate’s custom hydraulic manifolds optimize fluid control efficiency across offshore and onshore operations. Discover rugged, block-integrated solutions designed to eliminate leakage pathways and ensure uninterrupted uptime in your critical oilfield systems.

Maximum Operating Pressure

Up to 10,000 PSI (700 bar) standard / Custom up to 15,000 PSI

Material Grades

Stainless Steel 316L, Super Duplex, Carbon Steel (A350 LF2), Inconel 625/718 cladding

Flow Rate Capacity

Up to 1,200 LPM (317 GPM) based on cavity configurations

Port Configurations

SAE J518 Flanged, NPT, BSPP, and Autoclave medium/high-pressure connections

Design Standards

ISO 4401, ASME B31.3, API 6A compliance protocols

Order Type

Quantity Range

Lead Time*

Sample

1 – 3 Units

4 – 6 Weeks

Low-Volume Batch

5 – 20 Units

6 – 8 Weeks

Standard Production Run

21 – 100 Units

8 – 12 Weeks

High-Volume / Blanket Order

100+ Units

Scheduled contract delivery (Staggered dispatches)

*Listed timelines are indicative averages. Actual lead times depend on specific material availability (e.g., exotic alloy forging cycles), engineering design approval speeds, and custom testing requirements.

Product Description

Frigate’s hydraulic manifolds consolidate complex valve networks into a singular, compact block to maximize fluid efficiency and minimize pressure drops. CNC-machined to exacting tolerances, these robust blocks dramatically simplify field maintenance and eliminate standard pipe-fitting leakage risks in high-vibration oilfield machinery.

Surface Treatment

Electroless Nickel Plating (ENP), Zinc-Nickel, Phosphating, or Epoxy coating

Seal Compatibility

Viton (FKM), HNBR, PTFE with anti-explosive decompression (AED) properties

Cavity Types

Common Cavities (SUN, HydraForce standard) and custom proportional valve configurations

Operating Temperature

-46°C to +121°C (Standard Low-Temp Carbon Steel / Duplex ratings)

Non-Destructive Testing (NDT)

Radiography, Dye Penetrant (DP), Magnetic Particle (MPI), Ultrasonic testing

Manifold Type

Monoblock, modular bar, or multi-station sandwich configurations

Manifold Weight Capacity

From 5 kg compact blocks up to 2,500 kg heavy industrial blocks

Fluid Compatibility

Mineral oils, water-glycols, synthetic fluids, and aggressive offshore crude

Contamination Tolerance

Rated for ISO 4406 Cleanliness codes up to 16/14/11 with proper filtration

Certification Options

Third-party inspection certifications via DNV, ABS, or Bureau Veritas

Technical Advantages

By utilizing advanced multi-axis machining and proprietary internal boring paths, our manifolds reduce overall weight while maintaining exceptional structural integrity under cyclic fatigue. The integration of high-grade, corrosion-resistant cladding guarantees prolonged component lifespans, cutting total cost of ownership in harsh marine environments.

Let's Get Started

Need reliable Enclosure for your next project? Get in touch with us today, and we’ll help you find exactly what you need!

Industry Applications

Offshore Drilling Rigs & Drillships

Ensures safe, responsive control of top drives, drawworks, and tensioning systems under severe marine corrosion and high-pressure ocean conditions.

Subsea Production Systems (SPS)

Reliable fluid distribution modules for Subsea Umbilicals, Risers, and Flowlines (SURF), engineered to perform flawlessly at high hydrostatic pressures.

Blowout Preventer (BOP) Control Units

Delivers critical, fail-safe hydraulic power redirection to BOP stacks, ensuring instantaneous emergency shut-in capabilities when pressure spikes.

Land-Based Hydraulic Fracturing Units

Withstands intense vibration and abrasive environments, directing high-volume fluid transfers efficiently across multi-pump frac fleets on-site.

Wellhead Control Panels (WHCP)

Provides ultra-compact, leak-free surface valve control loops to manage automated safety valves and chemical injection lines remotely.

Offshore Supply Vessel (OSV) Deck Machinery

Powers robust marine winches, cranes, and A-frames, ensuring smooth proportional control during complex subsea deployment and recovery.
