Guardrails

Engineered for high-impact resilience, Frigate’s heavy-duty industrial guardrails provide certified perimeter protection and asset safety across critical infrastructure and highway networks. Built from high-tensile galvanized steel, our customizable barrier systems deliver uncompromised structural integrity to mitigate severe impact risks in demanding environments.

Material Composition

Hot-rolled steel conforming to IS 2062 / ASTM A36 grade

Base Metal Thickness

2.67 mm (Thrie-Beam) / 3.12 mm (W-Beam) options

Galvanization Standard

Hot-dip galvanized as per IS 1570 / ISO 1461

Zinc Coating Mass

Minimum 550 g/m² or 700 g/m² for coastal corridors

Profile Configurations

Standard W-Beam, Thrie-Beam, and Box-Beam variants

Order Type

Quantity Range

Lead Time*

Standard Batches

Up to 500 Linear Meters

5 – 7 Working Days

Bulk Institutional Orders

501 to 2,500 Linear Meters

12 – 15 Working Days

Custom Profiles / Large Scale

2,501 to 10,000+ Linear Meters

21 – 28 Working Days

High-Volume Projects

Exceeding 10,000 Linear Meters

Staggered dispatch; schedule on request

* Delivery timelines are indicative estimations based on standard production queues. Actual lead times may vary slightly based on customized tooling requirements, raw material localized pricing cycles, and site-specific engineering modifications.

Product Description

Frigate’s industrial guardrails are engineered as robust, energy-absorbing crash barriers designed to shield critical equipment, structural supports, and personnel from vehicular and equipment impacts. Manufactured through precision roll-forming processes, these systems balance rigidity and controlled deformation to absorb sudden physical kinetic loads while keeping structural damage to a minimum.

Yield Strength

Minimum 250 MPa to 310 MPa

Ultimate Tensile Strength

410 MPa to 490 MPa

Post Spacing Options

1.5 m, 2.0 m, or 3.0 m center-to-center intervals

Post Dimensions

C-Channel (150 x 75 x 5 mm) or Sigma Post profile

Hardware / Fasteners

High-tensile hex bolts, nuts, and washers (Grade 4.6 / 8.8)

End Terminal Options

Energy-absorbing fish-tail, bull-nose, and anchor terminals

Standard Section Length

4.318 m (effective length 4.0 m) or custom lengths

Impact Compliance

Evaluated under MASH TL-3 / EN 1317 (N2, H1, H2 containment)

Corrosion Resistance

Salt spray tested up to 1000 hours without red rust

Total Cost of Ownership

Low maintenance profile with a design lifecycle exceeding 25 years

Technical Advantages

Our guardrails feature a high-performance hot-dip galvanized finish that provides exceptional cathodic protection against severe atmospheric corrosion and industrial chemical exposure. The computer-modeled structural design ensures optimal load distribution across posts and anchors during high-velocity impacts, substantially lowering replacement costs and ongoing maintenance overheads.

Let's Get Started

Need reliable Enclosure for your next project? Get in touch with us today, and we’ll help you find exactly what you need!

Industry Applications

Highways & Expressway Corridors

Prevents vehicle errant run-offs on high-speed arterial roads, flyovers, and sharp curves while minimizing structural impact deceleration forces.

Logistics Parks & Fulfillment Centers

Shields heavy-duty loading docks, automated sorting lines, and structural building columns from forklift impacts and trailer docking misalignments.

Heavy Manufacturing Plants

Isolates active forklift transport pathways from vulnerable pedestrian walkways and critical machine control panels to maximize shop floor safety.

Aviation Cargo & Ground Support Zones

Protects multi-million dollar airport ground handling equipment and fuel storage infrastructure from service vehicle collisions.

Mining & Heavy Industrial Yards

Delivers rugged containment barriers along haul roads and stockyards capable of withstanding impacts from heavy industrial machinery and dump trucks.

Seaports & Bulk Material Terminals

Specially coated to withstand highly corrosive marine microclimates while securing container staging areas, crane tracks, and terminal borders.

Frigate Approved Quality Management System

At Frigate, quality is built into every stage of manufacturing. Our approved Quality Management System ensures that every material component.

Incoming Material Checking

Before production begins, all incoming materials are checked against specifications, drawings, and supplier documents.

In-Process Inspection

Quality is monitored during manufacturing to prevent defects and maintain process consistency.

Final Dimensional Checking

Finished parts are inspected before dispatch to confirm compliance with customer drawings and tolerances.

Packaging Control

Finished components are packed safely to prevent damage during handling and transportation.

Incoming Material Checking

In-Process Inspection

Final Dimensional Checking

Packaging Control

Quality Document

To help buyers evaluate our quality systems, we provide sample documents that reflect our inspection and reporting standards.

How We Delivered

Complex geometries engineered solutions that move businesses forward.

Solar Inverter Enclosure

units per month

Bento Boxes for D2C Segment

Units Manufactured Monthly

0 +

Defence-Grade Cable Supply

Cost savings

0 %

Flange Assembly for Pump

Faster Production

0 %

Having Doubts? Our FAQ

What structural standards do Frigate’s guardrails comply with?

Our infrastructure guardrails are manufactured and tested in strict compliance with international safety protocols like MASH (Manual for Assessing Safety Hardware) TL-3/TL-4 and European EN 1317 standards, alongside national highway authority provisions.

Can Frigate customize guardrail profiles for specific radius curves?

Yes, we provide pre-curved convex and concave W-beam and Thrie-beam sections engineered to fit specific radii from 2 m to 45 m, eliminating the need for hazardous on-site modification or cold-bending.

How does Frigate guarantee the long-term corrosion resistance of its barriers?

We utilize high-purity zinc for our deep hot-dip galvanization line, exceeding standard coating densities. This ensures an outer barrier layer that protects the underlying high-tensile steel from moisture, road salts, and chemical fumes.

Do you supply all the necessary installation hardware and anchor systems?

Every consignment includes full turnkey hardware components including high-tensile fasteners, lap bolts, spacer blocks, and base plates matched precisely to your installation format (ground-buried or surface flange-mounted).

What is the estimated total cost of ownership (TCO) advantage of Frigate guardrails?

Because our barriers are designed to withstand local atmospheric corrosion without degrading, they require near-zero structural maintenance for decades. This lowers your operational expenditure relative to painted alternative systems.
