Electrical Cabinets Eaton / GE Approved

Fabricated electrical cabinets manufactured to Eaton and GE approved enclosure specifications, dimensionally, structurally, and materially conformant to those manufacturers’ published cabinet standards. Frigate holds approved vendor status with both Eaton and GE, with type-tested construction documentation available to support project specifications and tender submissions that mandate approved enclosures. Cabinets are manufactured to the approved specification and supplied with full approval documentation, test reports, and material declarations per shipment.

Primary Material

Cold-rolled close-annealed (CRCA) steel 2.0–3.0 mm (IS 513 / EN 10130 CR4); 304 stainless steel available per approved configuration

Sheet Thickness

Structural frame: 2.5–3.0 mm; door and side panels: 2.0 mm; internal panels: 1.5–2.0 mm — per approved specification

Form Factor

Floor-standing; wall-mount; rack-mount — per approved Eaton or GE enclosure format; dimensions conform to published specification

Frame Dimensional Tolerance

±1.0 mm on external dimensions; ±0.5 mm on front face planarity; component mounting hole positions ±0.3 mm

IP Rating

IP31 / IP41 / IP54 / IP65 — variant per approved configuration and door/gland specification

*Approved cabinet supply does not require a new design or test cycle for configurations within the current approval scope. Scope confirmation adds 1–2 working days to the start of the manufacturing lead time.

Product Description

For project and tender submissions that mandate Eaton or GE approved enclosures, Frigate supplies the complete approval documentation package alongside the cabinet — type test reports, IEC 61439-1 verification statements, and material compliance declarations. This documentation is formatted to support submission to the engineering team or independent verification authority without additional processing. Approval documentation is current and maintained against the active approval scope.

Door Seal

EPDM or PVC compression gasket per approved specification; IP54 and above require continuous perimeter compression seal

Cable Entry

Top, bottom, and rear gland entry zones per approved configuration; EMC gland plates where specified

Busbar Support System

Insulated busbar supports per approved specification; positions and insulation material conform to the Eaton or GE published layout drawing

Custom Finish

Alternative RAL colours within approved material list; epoxy primer + polyurethane topcoat for corrosive environments; 304 SS mill finish

Environmental Compliance

RoHS 3; REACH SVHC <0.1% w/w; WEEE compliant; CE marking pathway for European market integration

Technical Advantages

Frigate manufactures cabinets within the approved specification scope, form factor, sheet thickness, busbar rating, component mounting provisions, gland entry configuration, and surface finish are all defined by the Eaton or GE enclosure standard. Modifications outside the approved specification are assessed individually for impact on approval status before production is confirmed. Where a project specification requires a configuration within the approved scope, Frigate can supply with full documentation without a new design or test cycle.

Let's Get Started

Need reliable Enclosure for your next project? Get in touch with us today, and we’ll help you find exactly what you need!

Industry Application

Industrial Motor Control Centres

Eaton and GE approved MCC enclosures for industrial motor control systems in oil and gas, petrochemical, and heavy manufacturing facilities. Approval status satisfies project engineering specifications that mandate type-tested enclosures from the approved vendor list.

Power Distribution Boards

Approved cabinet formats for main distribution boards, sub-distribution boards, and power factor correction panels where the end client’s specification references Eaton or GE approved enclosure construction and documentation.

Protection Relay & Control Panels

Approved enclosure formats for protection relay panels, SCADA interface cabinets, and control panels integrated with Eaton or GE protection and automation equipment. Dimensional conformance to the equipment manufacturer’s specification is verified at manufacture.

Utility & Power Generation

Approved enclosures for utility substation auxiliary systems, power plant control buildings, and switchyard relay rooms where Eaton or GE equipment is specified and the enclosure must carry the corresponding approval documentation for project sign-off.

Infrastructure & Building Services

Approved cabinet supply for building services electrical panels, infrastructure power distribution, and critical facility electrical rooms where the mechanical and electrical contractor’s specification references Eaton or GE approved enclosure construction.

Panel Builder Programmes

Ongoing supply to panel builders who build switchgear and control panels using Eaton or GE equipment and require pre-approved enclosures for all projects without managing individual approval submissions. Consistent documentation package per delivery regardless of project.

Frigate Approved Quality Management System

At Frigate, quality is built into every stage of manufacturing. Our approved Quality Management System ensures that every material component.

Incoming Material Checking

Before production begins, all incoming materials are checked against specifications, drawings, and supplier documents.

In-Process Inspection

Quality is monitored during manufacturing to prevent defects and maintain process consistency.

Final Dimensional Checking

Finished parts are inspected before dispatch to confirm compliance with customer drawings and tolerances.

Packaging Control

Finished components are packed safely to prevent damage during handling and transportation.

Incoming Material Checking

In-Process Inspection

Final Dimensional Checking

Packaging Control

Quality Document

To help buyers evaluate our quality systems, we provide sample documents that reflect our inspection and reporting standards.

How We Delivered

Complex geometries engineered solutions that move businesses forward.

Solar Inverter Enclosure

units per month

Bento Boxes for D2C Segment

Units Manufactured Monthly

0 +

Defence-Grade Cable Supply

Cost savings

0 %

Flange Assembly for Pump

Faster Production

0 %

Having Doubts? Our FAQ

Our project specification requires Eaton approved enclosures. How do we confirm Frigate's approval covers our specific equipment family?

Contact Frigate’s engineering team with the specific Eaton equipment family, cabinet format, current rating, and IP rating required. Written confirmation of approval status and documentation availability is returned within 1–2 working days before any order commitment is required.

We need a modification to the standard approved cabinet, does that void the approval?

It depends on the modification. Minor modifications, additional gland entries within the approved entry zone, standard RAL colour changes, bracket additions that don’t affect rated performance are typically within tolerance of the approved specification and do not require re-testing. Modifications that affect rated current path, short-circuit withstand, or IP rating are assessed individually against the approval scope before production is confirmed.

What specific type test reports does Frigate supply, and in what format?

Frigate supplies current IEC 61439-1 type test reports covering short-circuit withstand, temperature rise, dielectric, and mechanical impact tests, all conducted by an accredited test laboratory. Reports are in PDF format, identified by test report number, and formatted for direct submission to project verification authorities or independent checking engineers without additional processing.

We build panels using both Eaton and GE equipment across different projects. Can Frigate supply approved cabinets for both from a single source?

Yes. Frigate can supply approved cabinets for bo programmes under a single supply arrangement. Documentation is provided per shipment specific to the applicable manufacturer’s approval.

Our client's engineer is asking for a declaration that the cabinet is a type-tested assembly (TTA). Can Frigate provide that?

Yes. Frigate provides a written IEC 61439-1 TTA verification statement per shipment confirming that the cabinet is a type-tested assembly, not a partially type-tested or design-verified assembly. This statement, along with the supporting test reports, satisfies the TTA declaration requirement in project specifications and independent verification authority submissions.
