Audio equipment manufacturing requires transformers that ensure clear signal transfer and reliable performance across varied applications. Our Audio Line Matching & Output Transformers meet these needs with precise impedance matching and low distortion, supporting your production goals effectively.

Core Material

Silicon steel or nickel alloy (e.g., 80% nickel-iron) for low hysteresis and high permeability

Winding Material

Copper wire, enamel-coated (bifilar or trifilar optional) for optimal signal transfer

Voltage Rating

Primary – 1 V – 150 V; Secondary – 1 V – 150 V (customizable per audio circuit needs)

Power Rating

50 mW to 100 W, suited for audio signal amplification and matching

Frequency Range

20 Hz to 20 kHz (extendable to 100 kHz for high-fidelity applications)

Product Description

Poor signal quality or unreliable transformers can disrupt audio output and increase system failures. We engineer these units with silicon steel or nickel alloy cores and copper windings to maintain consistent sound quality up to 20 kHz, delivering dependable results for your audio systems.

Efficiency

85% to 95%, optimized for audio signal transfer with minimal loss

Temperature Range

Operating – -20°C to 85°C; maximum winding temperature rise – 50°C above ambient

Insulation Class

Class A (105°C) or Class B (130°C), depending on application requirements

Leakage Current

<0.1 mA at rated voltage, ensuring low interference in audio signals

Dimensions

Width – 20 mm to 80 mm; Height – 15 mm to 60 mm; Depth – 20 mm to 70 mm (customizable)

Weight

0.05 kg to 1 kg, depending on power rating and core size

Mounting Type

PCB mount, chassis mount, or plug-in terminals; adaptable to design specs

Noise Level

<20 dB at full load, minimized by core design and shielding for clean audio output

Protection Features

Electrostatic shielding (optional), short-circuit protection, and thermal overload options

Environmental Resistance

Moderate resistance to humidity (up to 80% RH) and vibration; meets IEC 60068-2-6

Standards Compliance

Meets or exceeds UL 5085-2, IEC 61558-2-6 (audio transformers), EN 55032 (EMI), and RoHS

Technical Advantages

Audio applications demand transformers that provide steady performance and fit seamlessly into your designs. Our Audio Line Matching & Output Transformers offer power ratings from 50 mW to 100 W and efficiencies of 85-95%, ensuring effective signal transfer for your manufacturing needs.

Inconsistent output or overheating can degrade sound quality and halt production. These units operate from -20°C to 85°C with low leakage current below 0.1 mA, keeping your audio systems stable and operational under regular use.

Let's Get Started

Need reliable Transformers for your next project? Get in touch with us today, and we’ll help you find exactly what you need!

Industry Applications

Professional Audio Systems

Matches impedance in amplifiers and mixers, ensuring high-quality sound for recording studios.

Consumer Audio Devices

Powers speakers and headphones, providing clean audio output for home entertainment products.

Public Address Systems

Supports microphones and loudspeakers, delivering stable signals for clear announcements.

Telecommunication Equipment

Enhances audio circuits in phones and intercoms, maintaining reliable voice transmission.

Broadcasting Technology

Drives radio and TV transmitters, ensuring consistent audio performance for media production.

Musical Instrument Amplifiers

Operates guitar and keyboard amps, supporting distortion-free sound for live performances.

Audio Transformers with Consistent Signal Integrity

Reliable audio production depends on transformers that minimize noise and support easy integration into your systems. Our Audio Line Matching & Output Transformers operate at under 20 dB and weigh between 0.05 kg and 1 kg, enabling quiet performance and straightforward assembly in your equipment.

Audio systems need consistent clarity and durability without frequent maintenance. These transformers incorporate strong core designs and shielding options to uphold your sound quality expectations, providing efficient, reliable performance over time.

Having Doubts? Our FAQ

Check all our Frequently Asked Question

How do your transformers ensure clear audio in our professional sound systems?

Our Audio Line Matching & Output Transformers use silicon steel or nickel alloy cores to deliver low-distortion signals up to 20 kHz. This design ensures your amplifiers and mixers produce high-quality sound with minimal interference.

Can these transformers adapt to different impedance levels in our audio designs?

Audio Line Matching & Output Transformers support customizable impedance matching for primary and secondary windings, ranging from 1 V to 150 V. Flexible configurations allow your team to align them precisely with diverse audio circuit requirements.

What benefits do we gain from low noise in our audio equipment production?

Our Audio Line Matching & Output Transformers operate at under 20 dB, reducing unwanted noise in speakers and microphones. Quiet performance enhances your product’s audio clarity, meeting customer expectations for premium sound quality.

How reliable are these transformers for long-term use in our broadcast systems?

Audio Line Matching & Output Transformers feature durable copper windings and optional shielding to withstand continuous operation. Their robust build minimizes signal degradation, ensuring consistent performance in your radio and TV transmitters over time.

Why should we choose your transformers for cost-effective audio manufacturing?

Our Audio Line Matching & Output Transformers offer 85-95% efficiency and power ratings from 50 mW to 100 W, optimizing energy use in production. Efficient operation reduces your overall system costs while maintaining reliable audio output.
