RF Coaxial Connectors

Name: RF Coaxial Connectors - Frigate
Price: 249.00 USD
Availability: InStock

When it comes to seamless communication, whether for telecommunications, broadcasting, or industrial applications, choosing the right RF (Radio Frequency) coaxial connectors is crucial. These connectors are essential for ensuring signal integrity, minimizing loss, and supporting high-frequency transmission. These connectors are pivotal in delivering reliability and performance at the core of your RF systems.

Material Options

Brass, Stainless Steel, Aluminum, Copper, Nickel-Plated

Cable Diameter Range

0.1 mm to 15 mm

Temperature Range

-40°C to +85°C

Load Capacity

500 N (depending on the connector type)

Vibration Resistance

Up to 10 g (IEC 60068-2-6 standard)

Product Description

One of the main concerns when handling high-frequency signals is maintaining signal integrity while minimizing losses. RF coaxial connectors are designed with a robust structure to ensure minimal signal attenuation, preserving the quality of your signal even across long distances or harsh environments. With precise design and materials, these connectors are built to handle high-frequency data transmission while keeping interference and signal degradation at bay.

Corrosion Resistance

Corrosion-resistant coatings, typically gold, nickel, or tin

EMI Shielding

90 dB (depending on connector design and material)

Mounting Options

Panel mount, bulkhead mount, surface mount, soldered

Compliance Standards

RoHS, UL, CE, MIL-STD-810G, IEC standards

Custom Features

Custom impedance (50Ω or 75Ω), low-profile designs, gold plating

UV Resistance

UV-resistant materials for outdoor applications

Fire Resistance Rating

UL 94 V-0 (self-extinguishing)

Chemical Resistance

Resistant to oils, fuels, acids, and cleaning solvents

Thermal Expansion Tolerance

Coefficient of expansion matched to cable insulation for stability

Dynamic Load Testing

Tested for up to 100,000 cycles of connection/disconnection

Precision Tolerances

±0.1 mm (depending on connector type and application)

Technical Advantages

Whether working in outdoor, industrial, or military-grade environments, RF coaxial connectors are built to last. They are made from corrosion-resistant materials like stainless steel or brass and are designed to withstand extreme temperatures, vibrations, and weather conditions. These qualities ensure your system maintains optimal performance, even in demanding environments.

RF systems often operate at frequencies ranging from MHz to GHz, where the smallest impedance or signal reflection mismatch can cause significant issues. Coaxial connectors are engineered to ensure a precise 50-ohm or 75-ohm impedance match, reducing signal reflection and power loss. This high-frequency performance ensures your systems operate efficiently without unexpected downtimes.

Let's Get Started

Need reliable Connectors for your next project? Get in touch with us today, and we’ll help you find exactly what you need!

Industry Applications

Telecommunications

Used in base stations, antenna systems, and signal distribution to maintain signal integrity over long distances.

Satellite Communications

Critical for high-frequency signal transmission between ground stations and satellites, ensuring minimal signal loss.

Broadcasting

Essential for transmitting video and audio signals in TV and radio broadcasting with minimal interference.

Automotive

Applied in-vehicle communication systems, radar, and sensor networks for reliable data transfer.

Aerospace

Used in avionics and navigation systems to ensure precise signal transmission in challenging environments.

Military

Provides secure and stable communications for defense systems, including radar, secure radios, and electronic warfare.

Protection and Performance for Critical Communications

RF coaxial connectors cater to a wide range of industries and applications. From high-speed internet networks to satellite communications and automotive testing to military communications, these connectors are adaptable to diverse needs. Whether building a high-speed data transmission network or a high-reliability communication system, RF connectors can be customized to meet your unique specifications.

RF signals are often vulnerable to external electromagnetic interference (EMI). RF coaxial connectors are designed with excellent shielding capabilities to protect your signal from unwanted noise. Multiple layers of shielding, including braided mesh or foil, effectively block interference and ensure that your data remains clear and uninterrupted.

Having Doubts? Our FAQ

Check all our Frequently Asked Question

How do RF coaxial connectors ensure minimal signal reflection at high frequencies?

RF coaxial connectors are engineered with precise impedance matching, typically 50-ohms or 75-ohms, to prevent signal reflections. Mismatched impedance can cause signal loss or distortion, especially at higher frequencies. These connectors maintain a constant impedance throughout the connection, ensuring minimal reflection and signal integrity for reliable data transmission.

What materials are commonly used in RF coaxial connectors to achieve superior shielding?

RF coaxial connectors use materials like brass, stainless steel, and nickel-plated coatings to effectively block electromagnetic interference (EMI). These materials are combined with multi-layered shielding, such as braided mesh, foil, or solid shields, which provide excellent protection against external noise. This shielding ensures clear signal transmission even in electrically noisy environments.

How do RF coaxial connectors maintain performance in extreme temperature conditions?

RF coaxial connectors are built with temperature-resistant materials like PTFE (Polytetrafluoroethylene) and specialized elastomers for insulation. These materials prevent signal degradation by maintaining stable electrical properties, even in temperatures ranging from -40°C to +85°C. This thermal stability ensures consistent performance in the aerospace, military, and telecommunications industries.

What role do RF coaxial connectors play in minimizing insertion loss in high-speed data transmission?

Insertion loss refers to the signal power lost when it passes through a connector. RF coaxial connectors are designed with low-resistance materials and precise internal structures to reduce insertion loss. Features like gold or silver plating on contact points, low-profile designs, and tight tolerances help maintain maximum signal strength, which is crucial for high-speed data transmission in applications like fiber optics and 5G networks.

How do RF coaxial connectors ensure reliable operation in harsh industrial environments?

In harsh environments, RF coaxial connectors are designed with rugged, corrosion-resistant materials like stainless steel and thermoplastic elastomers. They are also sealed to protect against dust, moisture, and chemicals, which could degrade the connector over time. These durable designs ensure connectors remain functional and maintain optimal performance even in industrial, automotive, or military applications, where exposure to extreme conditions is common.
