Double Compression Nickle Plated Brass Cable Glands

Safe & Secure Payments

Order Quantity (Units) Discount Offered
1 – 99 Base Price
100 – 499 5% Off
500 – 1,999 12% Off
2,000+ Custom Pricing
Double Compression Nickle Plated Brass Cable Glands
Double Compression Nickle Plated Brass Cable Glands - Image 2
Engineered for ultimate durability, Frigate’s Double Compression Nickel Plated Brass Cable Glands offer uncompromised environmental sealing and superior mechanical grip for armoured cables. Designed to excel in high-stress industrial environments, they provide certified weatherproof and flameproof protection you can rely on.

Material

Nickel Plated Brass

Ingress Protection Rating

IP66 / IP67 / IP68 (Variant Dependent)

Operating Temperature Range

-60° C to +125° C

Protection Class Options

Weather Proof (BPW) / Flame Proof (BPF)

Cable O.D. Accommodation

8 mm to 104 mm

Price Range:

Price range: $282.00 through $13,490.00 /per unit

  • Competitive Pricing
  • Order Flexibility
  • Volume Discounts
Request Bulk Quote

You're Protected With Every Order

Frigate ensures reliable electrical products, proper invoice support, and post-order assistance, so you can purchase with confidence.

100% Genuine Products

Direct from brand-authorised sources.

Manufacturer Assured

Warranty as per manufacturer terms.

GST Invoice

Compliant invoice with every order.

Technical Support

Expert help for product selection.

Business Features

Exclusive benefits for bulk buyers.

  • World Wide Delivery
  • Secure Payments
  • Dedicated Account Manager
  • Post-Order Support

Price & Specification Details

WEATHER PROOF FLAME PROOF
O.D. Range (mm) Nipple Entry Cat No. Rate / Unit Cat No. Rate / Unit
8 – 12 5/8″ BPW 3/8″ 282.00 BPF 3/8″ 324.00
8 – 13 5/8″ BPW 1/2″ 282.00 BPF 1/2″ 324.00
8 – 13 3/4″ BPW 001S 294.00 BPF 001S 338.00
11 – 15 3/4″ BPW 5/8″ 345.00 BPF 5/8″ 397.00
12.5 – 16.5 3/4″ BPW 001 345.00 BPF 001 397.00
12.5 – 16.5 3/4″ BPW 01S 370.00 BPF 01S 426.00
15 – 18 3/4″ BPW 01 420.00 BPF 01 483.00
15 – 18 1″ BPW 01L 474.00 BPF 01L 545.00
18 – 20 1″ BPW 02 536.00 BPF 02 616.00
18 – 20 3/4″ BPW 02S 555.00 BPF 02S 638.00
20 – 23 1″ BPW 1″ 536.00 BPF 1″ 616.00
20 – 23 1″ BPW 03 545.00 BPF 03 627.00
23 – 26 1″ BPW 04 744.00 BPF 04 856.00
23 – 26 1-1/4″ BPW 04L 822.00 BPF 04L 945.00
26 – 30 1-1/4″ BPW 05 926.00 BPF 05 1065.00
26 – 30 1-1/2″ BPW 05L 1064.00 BPF 05L 1224.00
30 – 33 1-1/2″ BPW 06 1324.00 BPF 06 1524.00
30 – 33 1-1/4″ BPW 06S 1348.00 BPF 06S 1550.00
33 – 37 1-1/2″ BPW 07 1566.00 BPF 07 1801.00
37 – 41 2″ BPW 08 1881.00 BPF 08 2163.00
41 – 46 2″ BPW 09 2034.00 BPF 09 2339.00
46 – 52 2″ BPW 010 2476.00 BPF 010 2847.00
46 – 52 2-1/2″ BPW 010L 2721.00 BPF 010L 3129.00
52 – 60 2-1/2″ BPW 011 3705.00 BPF 011 4261.00
60 – 66 3″ BPW 012 4357.00 BPF 012 4999.00
66 – 72 3″ BPW 013S 5606.00 BPF 013S 6447.00
72 – 78 3-1/4″ BPW 013 5914.00 BPF 013 6801.00
78 – 83 3-1/2″ BPW 014 7452.00 BPF 014 8570.00
83 – 93 4″ BPW 015 8694.00 BPF 015 9998.00
93 – 104 4-1/2″ BPW 016 11730.00 BPF 016 13490.00
Cat. No.
(Ref)		 Nipple
Length (mm)		 Gland Inner
Length(mm)		 Across
Flats (mm)		 Across
Corners (mm)		 Nipple
ET		 Nipple
MM		 Nipple
NPT		 Hole
Clearance (mm)		 Cable O.D.
Range(mm)
BPW-3/4″ 13 11 21 24 5/4″ M-16 1/2″ NPT 12 4 – 12
BPW-1/2″ 15 11 21 24 5/4″ M-16 1/2″ NPT 12 4 – 13
BPW-001S 14 13 21 24 3/4″ M-20 1/2″ NPT 12 4 – 13
BPW-5/4″ 17 14 23 26 3/4″ M-20 1/2″ NPT 15 11 – 15
BPW-001 17 14 24 27.5 3/4″ M-20 1/2″ NPT 15 12.5 – 16.5
BPW-01S 17.5 14 25 29 3/4″ M-20 1/2″ NPT 15 12.5 – 16.5
BPW-01 20 14 27 31 3/4″ M-20 1/2″ NPT 15 15 – 14
BPW-01L 20 15 27 31 1″ M-25 3/4″ NPT 15 15 – 14
BPW-02 20.5 14 30.5 35.5 1″ M-25 3/4″ NPT 15 14 – 20
BPW-02S 20.5 14 30.5 35.5 3/4″ M-20 1/2″ NPT 15 14 – 20
BPW-03 23 14 30.5 35.5 1″ M-25 3/4″ NPT 15 20 – 23
BPW-1″ 23 20 30.5 35.5 1″ M-25 3/4″ NPT 15 20 – 23
BPW-04 24 20 37 43 1″ M-25 3/4″ NPT 15 23 – 26
BPW-04L 24 24 37 43 1-1/4″ M-32 1″ NPT 15 23 – 26
BPW-05 31 25 41 47 1-1/4″ M-32 1″ NPT 15 26 – 30
BPW-05L 31 26 41 47 1-1/2″ M-40 1-1/4″ NPT 15 26 – 30
BPW-06 34 31 47 54.5 1-1/2″ M-40 1-1/4″ NPT 15 30 – 33
BPW-06S 34 24 47 54.5 1-1/4″ M-32 1″ NPT 15 30 – 33
BPW-07 39 33 51 59 1-1/2″ M-40 1-1/4″ NPT 15 33 – 37
BPW-04 43 34 54 62 2″ M-50 1-1/2″ NPT 15 37 – 41
BPW-09 47 40 56 65 2″ M-50 1-1/2″ NPT 15 41 – 46
BPW-010 53 44 66 76.5 2″ M-50 1-1/2″ NPT 20 46 – 52
BPW-010L 53 50 66 76.5 2-1/2″ M-63 2″ NPT 20 46 – 52
BPW-011 61 56 40 92 2-1/2″ M-63 2″ NPT 20 52 – 60
BPW-012 64 64 44 97 3″ M-75 2-1/2″ NPT 20 60 – 66
BPW-013S 73 67 90 104 3″ M-75 2-1/2″ NPT 20 66 – 72
BPW-013 79 75 94 113 3-1/4″ M-42 3″ NPT 20 72 – 74
BPW-014 45 74 103 119 3-1/2″ M-90 3″ NPT 20 74 – 43
BPW-015 94 91 112 129 4″ M-100 3-1/2″ NPT 24 43 – 93
BPW-016 106 100 125 144 4-1/2″ M-115 4″ NPT 25 93 – 104

Product Detail

Frigate’s high-performance double compression cable glands are precisely machined from premium brass and finished with robust nickel plating to handle demanding industrial connections. They create a secure, dual-tiered seal on both the inner and outer sheaths of armoured cables, effectively isolating critical wiring from external environmental hazards.

Nipple Thread Options (ET)

5/8 inch to 4-1/2 inch

Nipple Thread Options (Metric)

M-16 to M-115

Nipple Thread Options (NPT)

1/2 ” NPT to 4 ” NPT

Maximum Inner Clearance (D)

Up to 25 mm

Standard Compliance

Industrial Heavy Duty Grade

Finish

High-grade Corrosion Resistant Nickel Plating

Technical Advantages

By utilizing a dual-compression ring mechanism, these glands provide maximum mechanical retention and vibration resistance, preventing accidental cable pull-outs in high-stress machinery setups. Additionally, the premium nickel-plated coating offers outstanding galvanic corrosion resistance and superior thermal stability, ensuring long-term electrical continuity and flameproof protection in harsh or corrosive processing facilities.

Compliances

ISO 90012015

QA-AC-628923

Why customers choose FRIGATE?

Built on trust, manufacturing expertise, and long-term support.

5+ years of experience

Trusted for reliable manufacturing solutions.

World Wide delivery

From factories to doorsteps across the world.

Secure payments

Multiple safe options with full transaction security.

Dedicated account manager

Single point of contact for orders and queries.

Post-order support

Reliable support that stays with you after delivery.

Having Doubts? Our FAQ

Do these cable glands come with Material Test Certificates (MTC) and compliance documentation?

Yes. Every shipment from Frigate includes a standard Manufacturer’s Test Certificate (MTC) verifying the chemical composition of the brass alloy and nickel plating thickness. We can also provide specific compliance reports (such as RoHS or REACH certifications) upon request during order placement.

Which thread standards are supported by Frigate Cable Glands?

Our product range natively supports Imperial Straight (ET), Metric (M-Thread), and National Pipe Tapered (NPT) entry threads to easily match global machinery standards.

What is the typical lead time for high-volume or non-standard B2B orders?

Standard catalog sizes are regularly maintained in stock for immediate dispatch. For bulk contract orders or custom entry thread lengths, our typical production-to-delivery pipeline ranges from 2 to 4 weeks, depending on batch volume and specific machining requirements.

How are the gland threads protected during bulk transit?

To ensure zero thread damage or deformation during freight handling, all glands are fitted with high-density plastic thread-protection caps. Bulk orders are securely packed in moisture-resistant, heavy-duty seaworthy wooden crates or reinforced corrugated cartons tailored for international shipping.

Can these glands be customized for specific bulk projects?

Yes, Frigate specializes in customized industrial B2B delivery. We can modify specific thread lengths, material configurations, or supply specialized inner sealing rings based on your technical blueprint requirements.
